Compare a monitor gamma test pattern online. Match stripes and gray visually, review the estimate and check display settings before making calibration changes.
Adjust the slider until stripes blend with solid gray. The slider value is your gamma.
Step back from the screen 4-6 feet, squint slightly, and adjust the slider until the striped left side blends with the solid gray right side. The slider value when they match is your monitor gamma.
Target: gamma 2.2 (sRGB standard)
Was this tool helpful?Rate Monitor Gamma Test:2.8(6 ratings)Thanks for rating!
Monitor Gamma Test is a free, browser-based monitor gamma test using stripe-blend pattern.
Cost: Free, no signup
Install: None — runs in the browser
Privacy: Runs locally, no uploads
Platforms: Windows, macOS, Linux, Android, iOS
Time: Under a minute
How to Read the Monitor Gamma Test Pattern
This online monitor gamma test uses a stripe-and-gray pattern to help you compare how your display presents midtones. Adjust the pattern until the areas look similar under steady viewing conditions. The result is a visual estimate influenced by scaling, color management, viewing angle and room lighting; it is not a measured color profile.
The pattern places alternating black and white stripes beside a solid gray area. Change the slider and compare their apparent brightness from a consistent viewing position. Browser zoom and display scaling can alter fine stripes, so use the recommended scale and repeat the comparison before interpreting the estimate.
How to Read Your Result
Gamma 2.2: Correct sRGB calibration. Most modern desktop monitors target this.
Gamma 2.4: BT.1886 video standard, used by some TVs.
Gamma 1.8: Old Mac default (pre-OS X 10.6). Indicates uncalibrated display or wrong profile.
Gamma 2.0 or below: Washed-out shadows. Common on poor IPS panels with bad QC.
Gamma 2.6+: Crushed shadows. Common on very dim VA panels or with brightness set too low. Confirm with a black crush test — it counts which near-black steps have disappeared entirely.
How to Fix Wrong Gamma
Check monitor OSD — most monitors have a Gamma setting (often labeled 1.8/2.0/2.2/2.4). Set to 2.2.
Reset color profile — Windows Display Settings > Color management. Remove custom profiles.
Use a hardware colorimeter for true calibration (Datacolor SpyderX, X-Rite i1Display).
For a step-by-step reading workflow, use the monitor gamma test guide after the live tool: it explains when to change the monitor preset, OS color profile, GPU correction, HDR mode, and room lighting.
A gamma of about 2.2 is a common shorthand, but the sRGB transfer curve is not a single pure-power function. This visual comparison cannot verify the full curve or create a calibrated ICC profile. The W3C sRGB specification gives the precise distinction.
Can I use the gamma test image on an OLED monitor?
You can compare the pattern visually on a compatible display, including OLED. Keep HDR, brightness processing and viewing conditions consistent. A mismatch is a reason to investigate settings, not proof that the panel is defective.
Why does the pattern change when I zoom or move?
Fine stripes can be resampled by browser zoom or display scaling, and viewing angle changes apparent brightness. Repeat at the intended scale and a steady viewing position. Compare shadow and highlight visibility with the black level test and white level test before drawing conclusions.
