Free Open Source Backlight Bleed Test

Check your monitor for light leakage, IPS glow, and clouding using a full-screen dark display.

Click preview or press Enter Fullscreen →

Brightness

1.0×

Raise to reveal subtle edge glow

Test Color

Keys 1–4 switch colors in fullscreen

Dim your room Turn off room lights — bleed is much harder to see in bright environments.

Enter fullscreen Press the button above or click the preview. The screen fills with pure black.

Inspect edges & corners Look for bright patches, haze, or uneven glow. Raise brightness to reveal subtle bleed.

This test runs entirely in your browser. No data is collected or uploaded.

Rate Backlight Bleed Test: 5.0 (2 ratings)

What Is Backlight Bleed?

LCD monitors work by shining a powerful backlight through a liquid-crystal layer. When the crystals fail to fully block light near the edges or corners of the panel, that light “bleeds” through and appears as bright patches on dark screens. Backlight bleed is most visible in dim rooms on black backgrounds, and its severity can range from invisible to severe.

Why it happens. The backlight assembly sits behind the LCD layer and is held in place by a metal chassis. Slight gaps or uneven clamping pressure let light escape around the edges — a manufacturing tolerance issue common to all LCD panels.
Which panels are affected. All LCD technologies — TN, IPS and VA — can exhibit backlight bleed. IPS panels also produce a separate issue called IPS glow; VA panels are generally better at blocking light but can show clouding instead. OLED panels have no backlight at all, so they show no bleed — but they can develop image retention and burn-in instead.
When it matters most. Bleed is most noticeable during dark movie scenes, full-screen gaming at night, and any workflow with dark UI themes. On a bright desktop it is usually invisible.
Can it be fixed? Minor bleed often softens as a panel warms up and after a few months of use. Severe bleed rarely improves on its own.

How to Use This Backlight Bleed Test

Run a complete bleed inspection in under two minutes with no software install.

Prepare your environment. Turn off room lights or close the blinds. Even moderate ambient light can mask bleed that would be obvious in a darker room. Let the monitor warm up for two minutes at its normal brightness.
Enter fullscreen and inspect. Click Enter Fullscreen to fill the entire panel with pure black, then slowly scan the edges and all four corners. Bright or hazy patches near the frame are backlight bleed; irregular cloudiness toward the centre is VA clouding.
Adjust brightness and switch shades. Raise the brightness slider to surface subtle bleed that is invisible at 1.0×. Press keys 1–4 to switch shades — dark blue and dark red can reveal different bleed characteristics than pure black. Press Escape or Exit to leave fullscreen.
Confirm with a second test. Corner glow that moves when you move is not bleed. Cross-check with the screen uniformity test for panel-wide brightness variation, and with the black crush test to confirm your black point is set correctly before you judge the panel.

Backlight Bleed vs IPS Glow vs Clouding

These three display issues look similar but have different causes, locations and severity profiles. Knowing which one you have decides whether you keep the panel or start a return.

Issue	Where it appears	Changes with viewing angle?	Panel types	Severity range
Backlight bleed	Edges and corners, often as bright rectangular patches	No — fixed regardless of angle	All LCD (TN, IPS, VA)	Minor (normal) to severe (RMA territory)
IPS glow	Corners, as a diffuse silver-white haze or shimmer	Yes — shifts dramatically when you tilt your head	IPS and IPS variants (Nano IPS, AHVA)	Inherent to the technology — unavoidable, varies by panel
Clouding / dirty screen effect	Centre or spread across the panel as irregular dark patches	Minimal — mostly viewing-angle independent	Primarily VA panels	Minor to severe — varies widely between units

Testing tip: IPS glow is easiest to identify by sitting at your normal viewing distance and then leaning slowly left and right. If the corner haze shifts, it is IPS glow. If it stays fixed, it is backlight bleed. If dark scenes look flat rather than glowing, the problem is gamma, not the backlight — check that with the monitor gamma test.

Is My Backlight Bleed Normal?

Some degree of backlight bleed is present in nearly every LCD monitor. The question is whether yours falls within an acceptable range or crosses into actionable territory.

Minor bleed (normal). Small patches of light at one or two corners, visible only in a completely dark room at maximum brightness and invisible during typical desktop use. Within industry-standard tolerances — no action required.
Moderate bleed. Noticeable glow along one or more edges at normal brightness settings; distracting during dark movie scenes or night-time gaming. Whether to act depends on your sensitivity and how much of the return window is left.
Severe bleed (consider RMA). Bright bands visible even with moderate ambient light, covering more than a few centimetres of screen edge and clearly distracting during normal use. Most manufacturers treat this as a manufacturing defect eligible for replacement.
When to request a return. Act inside the return window if bleed is visible at normal brightness with the room lights on. Document it with photos taken in a dimmed room, and check the retailer’s dead-pixel policy — most cover obvious bleed under the same terms. Run the dead pixel test in the same session so a single RMA covers every panel fault you find.

For photo examples of each severity tier and a step-by-step return decision, read how much backlight bleed is normal.

Backlight Bleed Test FAQ

What is backlight bleed?

Backlight bleed occurs when the backlight on an LCD monitor leaks through the edges or corners of the panel, creating bright patches on dark screens. It is a manufacturing tolerance issue present to some degree in nearly all LCD monitors.

How do I test for backlight bleed?

Enter fullscreen mode to fill the entire panel with a pure black screen. Dim the room lights and look for bright or hazy patches near the edges and corners. Raise the brightness slider to reveal subtle bleed.

What is the difference between backlight bleed and IPS glow?

Backlight bleed appears as fixed bright patches near the panel edges regardless of viewing angle. IPS glow is a silver-white shimmer that appears in the corners and shifts when you change your viewing angle. Backlight bleed affects all LCD types; IPS glow is specific to IPS panels.

Is some backlight bleed normal?

Yes. Minor backlight bleed visible only in a dark room at maximum brightness is within normal manufacturing tolerances. Severe bleed visible at normal brightness with ambient lighting may be eligible for a replacement under the manufacturer warranty.

Does the brightness slider change my monitor settings?

No. The brightness slider uses a CSS filter applied in your browser and does not change your monitor's hardware backlight level. It helps reveal subtle bleed by making the test screen appear brighter without touching your display settings.
