Free Black Level Test

Free online black level test. Check whether your monitor crushes shadow detail with 32 near-black patches. Detect incorrect black-level mapping and gamma issues.

Download from Microsoft Store Download from Microsoft Store

Black Level Test

Count visible patches 1-32 on black background. All visible = healthy. Missing low = crushed blacks.

Count the gray patches on the black background. You should be able to see all 32, labelled 1 to 32. If the lowest numbers (1-5) are invisible, your monitor is crushing blacks - raise brightness or change the OSD black-level / Black eQualizer setting.
Best in a dark room — let your eyes adjust for about 5 minutes and set monitor brightness low.
Rate Black Level Test: 4.0 (9 ratings)

Black Level Test is a free, browser-based black level / crushed blacks test.

  • Cost: Free, no signup
  • Install: None — runs in the browser
  • Privacy: Runs locally, no uploads
  • Platforms: Windows, macOS, Linux, Android, iOS
  • Time: Under a minute

How to Use the Black Level Test Pattern

This black level test displays near-black patches so you can compare shadow detail against a black background. Use the monitor test pattern to spot shades that merge together, then repeat with consistent room lighting and display settings. The visible steps depend on the full display pipeline; this is not a measurement of absolute black luminance or a calibration certificate.

How to Read Your Result

  • All 32 visible: Excellent black level. Your monitor preserves shadow detail.
  • Visible from 4-32: Mild crushing. Monitor brightness too low or wrong gamma.
  • Visible from 8-32: Moderate crushing. Adjust monitor's "Black Level" setting in OSD or increase brightness.
  • Visible from 16+: Severe crushing. Monitor in "Limited" RGB range mode (16-235) instead of "Full" (0-255). Switch GPU output to Full RGB.

How to Fix Crushed Blacks

  1. Check GPU RGB range: Nvidia Control Panel > Display > Output dynamic range = Full. AMD: Display > Pixel Format = RGB 4:4:4 Full.
  2. Monitor OSD: Look for Black Level / Black eQualizer. Set to standard or normal.
  3. Brightness too low: Below 20%, near-black detail vanishes.
  4. Wrong gamma: Run our monitor gamma test. If gamma is too high (2.4+), shadows crush.

Need the full step-by-step workflow? Read the black crush test guide for brightness, HDMI black level, Full RGB, gamma, HDR, and OLED settings.

Black Level Test Questions and Answers

What should I look for in a black level test image?

Look for gradual separation between the near-black patches and background. Record which steps are hard to distinguish, then compare one setting at a time. Do not use an arbitrary requirement that every lowest-value patch must always be visible under every viewing condition.

Can this test measure an OLED monitor’s absolute black level?

No. The page supplies digital test values and you make a visual comparison. Measuring emitted black luminance requires suitable equipment and controlled conditions. OLED processing, HDR mode and near-black behavior can also affect what you see.

Is this a full 0–255 RGB test pattern?

This tool concentrates on near-black steps rather than the entire RGB range. Use the color range test for a broader range comparison and the white level test for highlight detail.

Should I change brightness, gamma or the input range first?

Record your current settings and verify that the source and display agree on signal range before experimenting. Change one setting at a time and retest normal images as well as the pattern. A visually crushed shadow does not identify a single cause by itself.
