Count visible patches 223-254 on white background. All visible = healthy. Missing high = clipped highlights.
Look for the gray patches on the white background. You should see all patches labeled 223 through 254. If high values (250-254) blend into white, your monitor is clipping highlights - reduce contrast or check the OSD.
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
Was this tool helpful?Rate White Level Test:5.0(3 ratings)Thanks for rating!
White Level Test is a free, browser-based white level / clipped highlights test.
Cost: Free, no signup
Install: None — runs in the browser
Privacy: Runs locally, no uploads
Platforms: Windows, macOS, Linux, Android, iOS
Time: Under a minute
How to Read the White Level Test Pattern
Use this monitor white level test to compare near-white shades and look for highlight detail that merges into the background. Keep the screen size, room lighting and picture mode consistent as you inspect the pattern. It is a visual clipping check, not a measurement of peak brightness, HDR capability or overall color accuracy.
How to Read Your Result
All 32 visible: Excellent white level. Highlights are preserved.
Visible up to 250: Mild clipping. Reduce contrast slightly.
Visible up to 245: Moderate clipping. Brightness too high or contrast set above 75%.
Visible only to 240 or lower: Severe clipping. GPU may be in Limited RGB range.
How to Fix Clipped Whites
Lower contrast in monitor OSD. Try 70-75% as a starting point.
Reduce HDR/Dynamic Contrast - these features amplify clipping.
Set GPU to Full RGB: Nvidia / AMD output range = Full / RGB 4:4:4.
Run gamma test: monitor gamma test - low gamma values can also clip highlights.
Look for small changes between the near-white patches and the white background. If several steps merge, compare another picture mode or source setting under the same viewing conditions. The result describes visibility in that setup, not a universal pass or fail for the monitor.
Is this an HDR white level or peak-brightness test?
No. A browser-rendered pattern is not a calibrated HDR signal generator or a luminance meter. HDR mode, tone mapping, browser color management and display processing can change the appearance of the page.
Can I check black and white levels together?
Use this page for highlight clipping and the black level test for shadow separation. Compare them after each setting change; improving one end of the range can make the other harder to distinguish.
Why does increasing contrast hide the brightest steps?
Some contrast or picture-processing settings can compress or clip highlights. Record the original setting, change one control and compare the same pattern again. Check normal photos or video before keeping a change.
