11 steps from black to white. All distinct = healthy. Merging steps = misconfigured.
You should see 11 distinct brightness steps from pure black on the left to pure white on the right. Each step should be visibly different from its neighbors. If steps in the middle look the same, your brightness or contrast is misconfigured.
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
Was this tool helpful?Rate Brightness Test:5.0(6 ratings)Thanks for rating!
Brightness Test is a free, browser-based screen testing tool that lets you check brightness, contrast, gamma, HDR clipping, and shadow detail.
Cost: Free, no signup
Install: None — runs in the browser
Privacy: Runs locally, no uploads
Platforms: Windows, macOS, Linux, Android, iOS
Time: Under a minute
Online Brightness Test With a Grayscale Pattern
This online monitor brightness test displays an 11-step grayscale pattern so you can compare dark, middle and bright shades. Use it to inspect visible separation under consistent room lighting, then change one display setting at a time. The pattern does not measure brightness in nits or prove that a phone, TV or monitor meets a peak-brightness specification.
How to Run the Brightness Calibration Test
Prepare the screen: set browser zoom to 100%, warm the display for a few minutes, and use fullscreen mode.
Disable moving targets: turn off HDR, Auto Brightness, Night Light, Dynamic Contrast, eco mode, and aggressive game presets before judging the ladder.
Read the 11 steps: every block should look separate from the one beside it, with no sudden jumps from black to gray or from light gray to white.
Adjust and repeat: start around 70-80% monitor brightness and 70-75% contrast, then tune for your room lighting and rerun the test.
How to Read the Grayscale Ladder
All 11 steps visible: brightness, contrast, and gamma are usable for normal viewing.
0-30% steps merge: brightness is too low, gamma is too high, or the GPU/HDMI range is mismatched. Confirm with the black level test.
70-100% steps merge: contrast is too high, HDR tone mapping is clipping, or Dynamic Contrast is active. Confirm with the white level test.
Middle steps look bunched or stretched: run the monitor gamma test and target gamma 2.2 for standard PC use.
Best Brightness Settings for Room Lighting
Choose a comfortable hardware brightness and compare the same grayscale pattern under your usual room lighting. Record the setting before making a change. The black screen test provides a separate dark-screen reference, while the PWM flicker test explains the limits of a qualitative camera observation. Neither page measures emitted luminance or certifies flicker-free output; a quantified brightness measurement needs suitable equipment and a defined method.
Monitor Brightness Test FAQ
What is a monitor brightness test?
A monitor brightness test is a visual grayscale calibration check. It displays 11 steps from black to white so you can see whether your screen preserves shadow detail, highlight detail, and smooth midtone spacing.
How do I read the 11-step grayscale result?
All 11 blocks should be distinct. Dark blocks merging means brightness is too low, gamma is too high, or the RGB range is wrong. Bright blocks merging means contrast is too high, HDR is clipping, or Dynamic Contrast is changing the image.
What brightness and contrast settings should I start with?
Use the monitor OSD as a starting point: brightness around 70-80% and contrast around 70-75%. Then adjust for your room lighting and rerun the ladder until the dark, middle, and bright steps all remain separate.
Should I turn off HDR, Night Light, or Auto Brightness first?
Yes. Disable HDR, Night Light, Auto Brightness, Dynamic Contrast, eco mode, and strong gaming picture presets before calibration. Those features change brightness or color while you are judging the test pattern.
Does this test measure actual nits or change my monitor brightness?
No. The page only renders test patterns in your browser. It does not read hardware luminance, measure nits, or change your monitor settings. Use it as a visual guide; use a colorimeter if you need certified brightness measurements.
Does the brightness test work on LCD, LED, OLED, laptop, and phone screens?
Yes. The grayscale ladder works on LCD, LED, OLED, laptop, tablet, and phone displays because it uses standard browser-rendered color patches. For the most repeatable result, test straight-on in stable room lighting.
